Description
MAIN FEATURES
Plastic housing
Resolution up to 2304×1296 at 20fps
Video compression S+265 H.265 H.264
Smart IR with 50 meter range
Two way talk with built in microphone and speaker
Supports WiFi connection
Supports human detection and tracking
Power supply DC 12V plus minus 25 percent
IP66 protection rating
CAMERA
Image sensor 1 over 2.9 inch CMOS
Minimum illumination color 0.02 lux at F1.6 AGC on black and white 0 lux with IR
Shutter time from 1 second to 1 over 100000 second
Day and night IR cut filter with auto switch ICR
Wide dynamic range DWDR
Signal to noise ratio greater than 38 decibel
Angle adjustment pan 0 to 294 degree tilt 0 to 90 degree
LENS
Lens type fixed
Focal length 4 millimeter
Lens mount M12
Aperture range F1.6 fixed
Field of view horizontal 81.6 degree vertical 43.1 degree diagonal 94.2 degree
DORI DISTANCE
Detect 57.14 meter
Observe 22.68 meter
Recognize 11.43 meter
Identify 5.71 meter
ILLUMINATOR
Infrared LEDs 6 pieces
Infrared distance 50 meter
Wavelength 850 nanometer
COMPRESSION
Video compression S plus 265 H.265 H.264B H.264M H.264H
Video bit rate 32 kilobit per second to 4 megabit per second
Audio compression G.711A G.711U
Audio sampling rate 8 kilohertz and 16 kilohertz
Maximum resolution 2304 by 1296 at 20 frames per second
Main stream PAL 20fps 2304 by 1296 1920 by 1080 1280 by 720 704 by 576 640 by 480
Main stream NTSC 20fps 2304 by 1296 1920 by 1080 1280 by 720 704 by 480 640 by 480
Sub stream PAL 20fps 704 by 576 704 by 288 352 by 288 640 by 360
Sub stream NTSC 20fps 704 by 480 704 by 240 352 by 240 640 by 360
